产品型号 |
WST35-2-GY | ||
|
宽度 Width |
16.1mm | ||
|
产品层数 Number of levels |
1 | ||
|
接线位数 Number of connections |
2 | ||
|
接线方式 Connection method |
笼式弹簧接线 | ||
|
防护等级 Protection Level |
IP20 | ||
|
工作温度 Work temperature |
-40~+105℃ | ||
IEC数据 /IEC Data
额定电流
Rated Current
125A
额定电压
Rated Voltage
1000V
过压类别
Overvoltage category
Ⅲ
污染等级
Pollution degree
3
额定冲击电压
Rated impulse voltage
8.0KV
刚性导线截面积
Conductor cross section solid
2.5-35mm²
柔性导线截面积
Conductor cross section flexible
2.5-35mm²
柔性导线截面积，带绝缘管套
Conductor cross section flexible,with furrule
2.5-35mm²
剥线长度
Stripping length
25mm
